Splunk SPLK-2002 Splunk Enterprise Certified Architect Exam Practice Test

The following statements about integrating with third-party systems are true: You can use Splunk alerts to provision actions on a third-party system, and you can forward data from Splunk forwarder to a third-party system without indexing it first. Splunk alerts are triggered events that can execute custom actions, such as sending an email, running a script, or calling a webhook. Splunk alerts can be used to integrate with third-party systems, such as ticketing systems, notification services, or automation platforms. For example, you can use Splunk alerts to create a ticket in ServiceNow, send a message to Slack, or trigger a workflow in Ansible. Splunk forwarders are Splunk instances that collect and forward data to other Splunk instances, such as indexers or heavy forwarders. Splunk forwarders can also forward data to third-party systems, such as Hadoop, Kafka, or AWS Kinesis, without indexing it first. This can be useful for sending data to other data processing or storage systems, or for integrating with other analytics or monitoring tools. A Hadoop application cannot search data in Splunk, because Splunk does not provide a native interface for Hadoop applications to access Splunk data. Splunk can search data in the Hadoop File System (HDFS), but only by using the Hadoop Connect app, which is a Splunk app that enables Splunk to index and search data stored in HDFS

Setting site=site0 on all Search Head Cluster members disables search site affinity. Search site affinity is a feature that allows search heads to preferentially search the peer nodes that are in the same site as the search head, to reduce network latency and bandwidth consumption. By setting site=site0, which is a special value that indicates no site, the search heads will search all peer nodes regardless of their site. Setting site=site0 does not set all members to dynamic captaincy, enable multisite search artifact replication, or enable automatic search site affinity discovery. Dynamic captaincy is a feature that allows any member to become the captain, and it is enabled by default. Multisite search artifact replication is a feature that allows search artifacts to be replicated across sites, and it is enabled by setting site_replication_factor to a value greater than 1. Automatic search site affinity discovery is a feature that allows search heads to automatically determine their site based on the network latency to the peer nodes, and it is enabled by setting site=auto

• The deployer is a Splunk Enterprise instance that distributes apps and other configurations to the members of a search head cluster1.
• The deployer cannot share functionality with any other Splunk Enterprise instance, including the license master, the master node, or the monitoring console2.
• However, the search head cluster members can share functionality with the master node and the monitoring console, as long as they are not designated as the captain of the cluster3.
• Therefore, the correct answer is B. License master, as it is the only instance that cannot share functionality with the deployer under any circumstances.

References: 1: About the deployer 2: Deployer system requirements 3: Search head cluster architecture

All of the forwarders would still be phoning home to the old deployment server, because the forwarders are configured to use the old deployment server in $SPLUNK_HOME/etc/system/local. This is the local configuration directory that contains the settings that override the default settings in $SPLUNK_HOME/etc/system/default. The deploymentclient.conf file in the local directory specifies the targetUri of the deployment server that the forwarder contacts for configuration updates and apps. If the forwarders have the old deployment server’s targetUri in the local directory, they will ignore the updated deploymentclient.conf file that was deployed by the old deployment server, because the local settings have higher precedence than the deployed settings. To fix this issue, the forwarders should either remove the deploymentclient.conf file from the local directory, or update it with the new deployment server’s targetUri. Option C is the correct answer. Option A is incorrect because a version mismatch between the forwarders and the new deployment server would not prevent the forwarders from phoning home to the new deployment server, as long as they are compatible versions. Option B is incorrect because the new deployment server is configured and running, and there is no indication that it is not accepting connections from the forwarders. Option D is incorrect because the pass4SymmKey is the shared secret key that the deployment server and the forwarders use to authenticate each other. It does not affect the forwarders’ ability to phone home to the new deployment server, as long as it is the same on both sides12

1: 2:

According to the Splunk documentation1, multi-site clustering is an indexer cluster that spans multiple physical sites, such as data centers. Each site has its own set of peer nodes and search heads. Each site also obeys site-specific replication and search factor rules. The use cases that are made possible by multi-site clustering are:

• Greatly reduce WAN traffic by preferentially searching assigned site (search affinity). This means that if you configure each site so that it has both a search head and a full set of searchable data, the search head on each site will limit its searches to local peer nodes. This eliminates any need, under normal conditions, for search heads to access data on other sites, greatly reducing network traffic between sites2.
• Seamlessly route searches to a redundant site in case of a site failure. This means that by storing copies of your data at multiple locations, you maintain access to the data if a disaster strikes at one location. Multisite clusters provide site failover capability. If a site goes down, indexing and searching can continue on the remaining sites, without interruption or loss of data2.

The other options are false because:

• Use blockchain technology to audit search activity from geographically dispersed data centers. This is not a use case of multi-site clustering, as Splunk does not use blockchain technology to audit search activity. Splunk uses its own internal logs and metrics to monitor and audit search activity3.
• Enable a forwarder to send data to multiple indexers. This is not a use case of multi-site clustering, as forwarders can send data to multiple indexers regardless of whether they are in a single-site or multi-site cluster. This is a basic feature of forwarders that allows load balancing and high availability of data ingestion4.

When installing Enterprise Security on a Search Head Cluster (SHC), the following steps should be done: Install Enterprise Security on the deployer, and use the deployer to deploy Enterprise Security to the cluster members. Enterprise Security is a premium app that provides security analytics and monitoring capabilities for Splunk. Enterprise Security can be installed on a SHC by using the deployer, which is a standalone instance that distributes apps and other configurations to the SHC members. Enterprise Security should be installed on the deployer first, and then deployed to the cluster members using the splunk apply shcluster-bundle command. Enterprise Security should not be installed on a staging instance, because a staging instance is not part of the SHC deployment process. Enterprise Security configurations should not be copied to the deployer, because they are already included in the Enterprise Security app package.

The __introspection log file contains data about the impact of the Splunk software on the host system, such as CPU, memory, disk, and network usage, as well as KV store performance1. This log file is monitored by default and the contents are sent to the _introspection index1. The other options are not related to the __introspection log file. File monitor input configurations are stored in inputs.conf2. File monitor checkpoint offset is stored in fishbucket3. User activities and knowledge objects are stored in the _audit and _internal indexes respectively4.

• inputs.conf is a configuration file that contains settings for various types of data inputs, such as files, directories, network ports, scripts, and so on1.
• initCrcLength is a setting that specifies the number of characters that the input uses to calculate the CRC (cyclic redundancy check) of a file1. The CRC is a value that uniquely identifies a file based on its content2.
• crcSalt is another setting that adds a string to the CRC calculation to force the input to consume files that have matching CRCs1. This can be useful when files have identical headers or when files are renamed or rolled over2.
• When troubleshooting a situation where some files within a directory are not being indexed, the ignored files are discovered to have long headers, the first thing that should be added to inputs.conf is to increase the value of initCrcLength. This is because by default, the input only performs CRC checks against the first 256 bytes of a file, which means that files with long headers may have matching CRCs and be skipped by the input2. By increasing the value of initCrcLength, the input can use more characters from the file to calculate the CRC, which can reduce the chances of CRC collisions and ensure that different files are indexed3.
• Option C is the correct answer because it reflects the best practice for troubleshooting this situation. Option A is incorrect because decreasing the value of initCrcLength would make the CRC calculation less reliable and more prone to collisions. Option B is incorrect because adding a crcSalt with a static string would not help differentiate files with long headers, as they would still have matching CRCs. Option D is incorrect because adding a crcSalt with the attribute would add the full directory path to the CRC calculation, which would not help if the files are in the same directory2.

References:

1: inputs.conf - Splunk Documentation 2: How the Splunk platform handles log file rotation 3: Solved: Configure CRC salt - Splunk Community

 The following artifacts are included in a Splunk diag file:

• Server specs. These are the specifications of the server that Splunk runs on, such as the CPU model, the memory size, the disk space, and the network interface. These specs can help understand the Splunk hardware requirements and performance.
• Current open connections. These are the connections that Splunk has established with other Splunk instances or external sources, such as forwarders, indexers, search heads, license masters, deployment servers, and data inputs. These connections can help understand the Splunk network topology and communication.
• Internal Splunk log files. These are the log files that Splunk generates to record its own activities, such as splunkd.log, metrics.log, audit.log, and others. These logs can help troubleshoot Splunk issues and monitor Splunk performance.
• Index listings. These are the listings of the indexes that Splunk has created and configured, such as the index name, the index location, the index size, and the index attributes. These listings can help understand the Splunk data management and retention. The following artifacts are not included in a Splunk diag file:
• Search history. This is the history of the searches that Splunk has executed, such as the search query, the search time, the search results, and the search user. This history is not part of the Splunk diag file, but it can be accessed from the Splunk Web interface or the audit.log file.
• Splunk users and their roles. These are the users that Splunk has created and assigned roles to, such as the user name, the user password, the user role, and the user capabilities. These users and roles are not part of the Splunk diag file, but they can be accessed from the Splunk Web interface or the authentication.conf and authorize.conf files.
• KV store listings. These are the listings of the KV store collections and documents that Splunk has created and stored, such as the collection name, the collection schema, the document ID, and the document fields. These listings are not part of the Splunk diag file, but they can be accessed from the Splunk Web interface or the mongod.log file.
• Indexed data. These are the data that Splunk indexes and makes searchable, such as the rawdata and the tsidx files. These data are not part of the Splunk diag file, as they may contain sensitive or confidential information. For more information, see Generate a diagnostic snapshot of your Splunk Enterprise deployment in the Splunk documentation.

The captain is the search head cluster component that is responsible for pushing knowledge bundles to search peers, replicating configuration changes to search head cluster members, and scheduling jobs across the search head cluster. The captain is elected from among the search head cluster members and performs these tasks in addition to serving search requests. The master is the indexer cluster component that is responsible for managing the replication and availability of data across the peer nodes. The deployer is the standalone instance that is responsible for distributing apps and other configurations to the search head cluster members. The deployment server is the instance that is responsible for distributing apps and other configurations to the deployment clients, such as forwarders

A dedicated deployment server is a Splunk instance that manages the distribution of configuration updates and apps to a set of deployment clients, such as forwarders, indexers, or search heads. A dedicated deployment server should be used when there are more than 50 deployment clients, because this number exceeds the recommended limit for a non-dedicated deployment server. A non-dedicated deployment server is a Splunk instance that also performs other roles, such as indexing or searching. Using a dedicated deployment server can improve the performance, scalability, and reliability of the deployment process. Option C is the correct answer. Option A is incorrect because the number of search peers does not affect the need for a dedicated deployment server. Search peers are indexers that participate in a distributed search. Option B is incorrect because the number of apps to deploy does not affect the need for a dedicated deployment server. Apps are packages of configurations and assets that provide specific functionality or views in Splunk. Option D is incorrect because the number of server classes does not affect the need for a dedicated deployment server. Server classes are logical groups of deployment clients that share the same configuration updates and apps12

1: 2:

The splunk rebuild command is used for thawing the archive bucket. Thawing is the process of restoring frozen data back to Splunk for searching. Frozen data is data that has been archived or deleted from Splunk after reaching the end of its retention period. To thaw a bucket, the user needs to copy the bucket from the archive location to the thaweddb directory under SPLUNK_HOME/var/lib/splunk and run the splunk rebuild command to rebuild the .tsidx files for the bucket. The splunk collect command is used for collecting diagnostic data from a Splunk instance. The splunk convert command is used for converting configuration files from one format to another. The splunk dbinspect command is used for inspecting the status and properties of the buckets in an index.

When adding or decommissioning a member from a Search Head Cluster (SHC), the proper order of operations is:

• Delete Splunk Enterprise, if it exists.
• Install and initialize the instance.
• Join the SHC.

This order of operations ensures that the member has a clean and consistent Splunk installation before joining the SHC. Deleting Splunk Enterprise removes any existing configurations and data from the instance. Installing and initializing the instance sets up the Splunk software and the required roles and settings for the SHC. Joining the SHC adds the instance to the cluster and synchronizes the configurations and apps with the other members. The other order of operations are not correct, because they either skip a step or perform the steps in the wrong order.

Splunk indexing is read/write intensive, as it involves reading data from various sources, writing data to disk, and reading data from disk for searching and reporting. Therefore, it is important to select the appropriate disk storage solution for each deployment, based on the performance, reliability, and cost requirements. The recommended RAID setup for Splunk indexers is RAID 10 (1 + 0), as it provides the best balance of performance and reliability. RAID 10 combines the advantages of RAID 1 (mirroring) and RAID 0 (striping), which means that it offers both data redundancy and data distribution. RAID 10 can tolerate multiple disk failures, as long as they are not in the same mirrored pair, and it can improve the read and write speed, as it can access multiple disks in parallel2

High performance SAN (Storage Area Network) can be used for Splunk indexers, but it is not recommended, as it is more expensive and complex than local disks. SAN also introduces additional network latency and dependency, which can affect the performance and availability of Splunk indexers. SAN is more suitable for Splunk search heads, as they are less read/write intensive and more CPU intensive2

NFS (Network File System) should not be used for storing hot and warm buckets, as it can cause data corruption, data loss, and performance degradation. NFS is a network-based file system that allows multiple clients to access the same files on a remote server. NFS is not compatible with Splunk index replication and search head clustering, as it can cause conflicts and inconsistencies among the Splunk instances. NFS is also slower and less reliable than local disks, as it depends on the network bandwidth and availability. NFS can be used for storing cold and frozen buckets, as they are less frequently accessed and less critical for Splunk operations2

Virtualized environments are not usually preferred over bare metal for Splunk indexers, as they can introduce additional overhead and complexity. Virtualized environments can affect the performance and reliability of Splunk indexers, as they share the physical resources and the network with other virtual machines. Virtualized environments can also complicate the monitoring and troubleshooting of Splunk indexers, as they add another layer of abstraction and configuration. Virtualized environments can be used for Splunk indexers, but they require careful planning and tuning to ensure optimal performance and availability2

According to the Splunk documentation1, when migrating an indexer cluster from single-site to multi-site, you must remove the existing single-site attributes from the server.conf file of each peer node. These attributes include replication_factor, search_factor, and cluster_label. You must also restart each peer node after removing the attributes. The other options are false because:

• Multi-site policies will apply only to the data created after migration, unless you configure the manager node to convert legacy buckets to multi-site1.
• All peer nodes do not need to run the same version of Splunk, as long as they are compatible with the manager node2.
• Single-site buckets can be converted to multi-site buckets by changing the constrain_singlesite_buckets setting in the manager node’s server.conf file to "false"1.

 The splunk diag --exclude command is a way to exclude search artifacts when creating a diag. A diag is a diagnostic snapshot of a Splunk instance that contains various logs, configurations, and other information. Search artifacts are temporary files that are generated by search jobs and stored in the dispatch directory. Search artifacts can be excluded from the diag by using the --exclude option and specifying the dispatch directory. The splunk diag --debug --refresh command is a way to create a diag with debug logging enabled and refresh the diag if it already exists. The splunk diag --disable=dispatch command is not a valid command, because the --disable option does not exist. The splunk diag --filter-searchstrings command is a way to filter out sensitive information from the search strings in the diag

The guidance Splunk gives for estimating size on for syslog data is 50% of original data size. This divides between files in the index as follows: rawdata is 15%, tsidx is 35%. The rawdata is the compressed version of the original data, which typically takes about 15% of the original data size. The tsidx is the index file that contains the time-series metadata and the inverted index, which typically takes about 35% of the original data size. The total size of the rawdata and the tsidx is about 50% of the original data size. For more information, see [Estimate your storage requirements] in the Splunk documentation.

Migration from single-site to multisite index replication only affects new data, not existing data. Multisite policies apply to new data only, meaning that data that is ingested after the migration will follow the multisite replication and search factors. Existing data, or data that was ingested before the migration, will retain the single-site policies, unless they are manually converted to multisite buckets. Single-site buckets do not instantly receive the multisite policies, nor do they automatically convert to multisite buckets. Multisite total values can exceed any single-site factors, as long as they do not exceed the number of peer nodes in the cluster. A master node is not required at each site, only one master node is needed for the entire cluster

Searching for closed_txn=0 in this search filters results to situations where Splunk was started, but not stopped. This means that the transaction was not completed, and Splunk crashed before it could finish the pipelines. The closed_txn field is added by the transaction command, and it indicates whether the transaction was closed by an event that matches the endswith condition1. A value of 0 means that the transaction was not closed, and a value of 1 means that the transaction was closed1. Therefore, option D is the correct answer, and options A, B, and C are incorrect.

1: transaction command overview

To expand the search head cluster by adding a new member, node2, the first step is to initialize the cluster configuration on node2 using the splunk init shcluster-config command. This command sets the required parameters for the cluster member, such as the management URI, the replication port, and the shared secret key. The management URI must be unique for each cluster member and must match the URI that the deployer uses to communicate with the member. The replication port must be the same for all cluster members and must be different from the management port. The secret key must be the same for all cluster members and must be encrypted using the splunk _encrypt command. The master_uri parameter is optional and specifies the URI of the cluster captain. If not specified, the cluster member will use the captain election process to determine the captain. Option C shows the correct syntax and parameters for the splunk init shcluster-config command. Option A is incorrect because the splunk bootstrap shcluster-config command is used to bring up the first cluster member as the initial captain, not to add a new member. Option B is incorrect because the master_uri parameter is not required and the mgmt_uri parameter is missing. Option D is incorrect because the splunk add shcluster-member command is used to add an existing search head to the cluster, not to initialize a new member12

1: 2:

 The splunk add cluster-master command is used to configure the same search head to join another indexer cluster. A search head can search multiple indexer clusters by adding multiple cluster-master entries in its server.conf file. The splunk add cluster-master command can be used to add a new cluster-master entry to the server.conf file, by specifying the host name and port number of the master node of the other indexer cluster. The splunk add cluster-config command is used to configure the search head to join the first indexer cluster, not the second one. The splunk edit cluster-config command is used to edit the existing cluster configuration of the search head, not to add a new one. The splunk edit cluster-master command does not exist, and it is not a valid command.

• KV Store is a feature of Splunk Enterprise that allows apps to store and retrieve data within the context of an app1.
• KV Store resides on search heads and replicates data across the members of a search head cluster1.
• KV Store resiliency refers to the ability of KV Store to maintain data availability and consistency in the event of failures or disruptions2.
• One of the factors that affects KV Store resiliency is the network latency between search heads, which can impact the speed and reliability of data replication2.
• Decreasing latency between search heads can improve KV Store resiliency by reducing the chances of data loss, inconsistency, or corruption2.
• The other options are not directly related to KV Store resiliency. Faster storage, indexer CPU and memory, and Operations Log size may affect other aspects of Splunk performance, but not KV Store345.

References: 1: About the app key value store 2: Configure and deploy KV Store using Splunk Enterprise 3: Creating and CRUDing a KV Store in Splunk: Part 1 4: KV store troubleshooting tools 5: Solved: Re: Disabling KV store

Multiple search pipelines should be enabled only if CPU and memory resources are significantly under-utilized. Search pipelines are the processes that execute search commands and return results. Multiple search pipelines can improve the search performance by running concurrent searches in parallel. However, multiple search pipelines also consume more CPU and memory resources, which can affect the overall system performance. Therefore, multiple search pipelines should be enabled only if there are enough CPU and memory resources available, and if the system is not bottlenecked by disk I/O or network bandwidth. The number of concurrent users, the disk IOPS, and the Splunk Enterprise version are not relevant factors for enabling multiple search pipelines

A multisite indexer cluster is a type of indexer cluster that spans multiple geographic locations or sites. A multisite indexer cluster requires only one cluster manager, also known as the master node, for the entire cluster. The cluster manager is responsible for coordinating the replication and search activities among the peer nodes across all sites. The cluster manager can reside in any site, but it must be accessible by all peer nodes and search heads in the cluster. Option C is the correct answer. Option A is incorrect because having two cluster managers for the entire cluster would introduce redundancy and complexity. Option B is incorrect because having one cluster manager for each site would create separate clusters, not a multisite cluster. Option D is incorrect because having two cluster managers for each site would be unnecessary and inefficient12

1: 2:

 A multi-site indexer cluster can be configured by directly editing SPLUNK_HOME/etc/system/local/server.conf or running a splunk edit cluster-config command from the CLI. These methods allow the administrator to specify the site attribute for each indexer node and the site_replication_factor and site_search_factor for the cluster. Configuring a multi-site indexer cluster via Splunk Web or directly editing SPLUNK_HOME/etc/system/default/server.conf are not supported methods. For more information, see Configure the indexer cluster with server.conf in the Splunk documentation.

Adding more search peers and making sure forwarders distribute data evenly across all indexers will provide the most search performance improvement when the distributed deployment is approaching its capacity. Adding more search peers will increase the search concurrency and reduce the load on each indexer. Distributing data evenly across all indexers will ensure that the search workload is balanced and no indexer becomes a bottleneck. Replacing the indexer storage to SSD will improve the search performance, but it is a costly and time-consuming option. Adding more search heads will not improve the search performance if the indexers are the bottleneck. Rescheduling slow searches to run during an off-peak time will reduce the search contention, but it will not improve the search performance for each individual search. For more information, see [Scale your indexer cluster] and [Distribute data across your indexers] in the Splunk documentation.

Increasing the number of parallel ingestion pipelines in server.conf is most likely to improve indexing performance when indexing is slow and real-time search results are delayed in a Splunk environment with two indexers and one search head. The parallel ingestion pipelines allow Splunk to process multiple data streams simultaneously, which increases the indexing throughput and reduces the indexing latency. Increasing the maximum number of hot buckets in indexes.conf will not improve indexing performance, but rather increase the disk space consumption and the bucket rolling time. Decreasing the maximum size of the search pipelines in limits.conf will not improve indexing performance, but rather reduce the search performance and the search concurrency. Decreasing the maximum concurrent scheduled searches in limits.conf will not improve indexing performance, but rather reduce the search capacity and the search availability. For more information, see Configure parallel ingestion pipelines in the Splunk documentation.

The client filters available in serverclass.conf are DNS name, IP address, and platform (machine type). These filters allow the administrator to specify which forwarders belong to a server class and receive the apps and configurations from the deployment server. The Splunk server role is not a valid client filter in serverclass.conf, as it is not a property of the forwarder. For more information, see [Use forwarder management filters] in the Splunk documentation.

Intermediate forwarders are forwarders that receive data from other forwarders and then send that data to indexers. They can be useful in some scenarios, such as when network bandwidth or security constraints prevent direct forwarding to indexers, or when data needs to be routed, cloned, or modified in transit. However, intermediate forwarders also introduce additional complexity and overhead to the data pipeline, which can affect the performance and reliability of data ingestion. Therefore, intermediate forwarders should be avoided when possible, and used only when there is a clear benefit or requirement for them. Some of the drawbacks of intermediate forwarders are:

• They increase the number of hops and connections in the data flow, which can introduce latency and increase the risk of data loss or corruption.
• They consume more resources on the hosts where they run, such as CPU, memory, disk, and network bandwidth, which can affect the performance of other applications or processes on those hosts.
• They require additional configuration and maintenance, such as setting up inputs, outputs, load balancing, security, monitoring, and troubleshooting.
• They can create data duplication or inconsistency if they are not configured properly, such as when using cloning or routing rules.

Some of the references that support this answer are:

• Configure an intermediate forwarder, which states: “Intermediate forwarding is where a forwarder receives data from one or more forwarders and then sends that data on to another indexer. This kind of setup is useful when, for example, you have many hosts in different geographical regions and you want to send data from those forwarders to a central host in that region before forwarding the data to an indexer. All forwarder types can act as an intermediate forwarder. However, this adds complexity to your deployment and can affect performance, so use it only when necessary.”
• Intermediate data routing using universal and heavy forwarders, which states: “This document outlines a variety of Splunk options for routing data that address both technical and business requirements. Overall benefits Using splunkd intermediate data routing offers the following overall benefits: … The routing strategies described in this document enable flexibility for reliably processing data at scale. Intermediate routing enables better security in event-level data as well as in transit. The following is a list of use cases and enablers for splunkd intermediate data routing: … Limitations splunkd intermediate data routing has the following limitations: … Increased complexity and resource consumption. splunkd intermediate data routing adds complexity to the data pipeline and consumes resources on the hosts where it runs. This can affect the performance and reliability of data ingestion and other applications or processes on those hosts. Therefore, intermediate routing should be avoided when possible, and used only when there is a clear benefit or requirement for it.”
• Use forwarders to get data into Splunk Enterprise, which states: “The forwarders take the Apache data and send it to your Splunk Enterprise deployment for indexing, which consolidates, stores, and makes the data available for searching. Because of their reduced resource footprint, forwarders have a minimal performance impact on the Apache servers. … Note: You can also configure a forwarder to send data to another forwarder, which then sends the data to the indexer. This is called intermediate forwarding. However, this adds complexity to your deployment and can affect performance, so use it only when necessary.”

To activate replication for an index in an indexer cluster, the repFactor attribute must be configured in indexes.conf on all peer nodes. This attribute specifies the replication factor for the index, which determines how many copies of raw data are maintained by the cluster. Setting the repFactor attribute to auto will enable replication for the index. The replicate attribute in indexes.conf is not a valid Splunk attribute. The repFactor attribute in outputs.conf and the replicate attribute in deploymentclient.conf are not related to replication for an index in an indexer cluster. For more information, see Configure indexes for indexer clusters in the Splunk documentation.

 The following statements are true about Splunk indexer clustering:

• All peer nodes must run exactly the same Splunk version. This is a requirement for indexer clustering, as different Splunk versions may have different data formats or features that are incompatible with each other. All peer nodes must run the same Splunk version as the master node and the search heads that connect to the cluster.
• The search head must run the same or a later Splunk version than the peer nodes. This is a recommendation for indexer clustering, as a newer Splunk version may have new features or bug fixes that improve the search functionality or performance. The search head should not run an older Splunk version than the peer nodes, as this may cause search errors or failures. The following statements are false about Splunk indexer clustering:
• The master node must run the same or a later Splunk version than the search heads. This is not a requirement or a recommendation for indexer clustering, as the master node does not participate in the search process. The master node should run the same Splunk version as the peer nodes, as this ensures the cluster compatibility and functionality.
• The peer nodes must run the same or a later Splunk version than the master node. This is not a requirement or a recommendation for indexer clustering, as the peer nodes do not coordinate the cluster activities. The peer nodes should run the same Splunk version as the master node, as this ensures the cluster compatibility and functionality. For more information, see [About indexer clusters and index replication] and [Upgrade an indexer cluster] in the Splunk documentation.

All of the options are possible causes of a crash in Splunk. According to the Splunk documentation1, incorrect ulimit settings can lead to file descriptor exhaustion, which can cause Splunk to crash or hang. Insufficient disk IOPS can also cause Splunk to crash or become unresponsive, as Splunk relies heavily on disk performance2. Insufficient memory can cause Splunk to run out of memory and crash, especially when running complex searches or handling large volumes of data3. Running out of disk space can cause Splunk to stop indexing data and crash, as Splunk needs enough disk space to store its data and logs4.

1: Configure ulimit settings for Splunk Enterprise 2: Troubleshoot Splunk performance issues 3: Troubleshoot memory usage 4: Troubleshoot disk space issues

This is the index that records changes to .conf files as of Splunk 9.0. According to the Splunk documentation1, the _configtracker index tracks the changes made to the configuration files on the Splunk platform, such as the files in the etc directory. The _configtracker index can help monitor and troubleshoot the configuration changes, and identify the source and time of the changes1. The other options are not indexes that record changes to .conf files. Option B, _introspection, is an index that records the performance metrics of the Splunk platform, such as CPU, memory, disk, and network usage2. Option C, _internal, is an index that records the internal logs and events of the Splunk platform, such as splunkd, metrics, and audit logs3. Option D, _audit, is an index that records the audit events of the Splunk platform, such as user authentication, authorization, and activity4. Therefore, option A is the correct answer, and options B, C, and D are incorrect.

1: About the _configtracker index 2: About the _introspection index 3: About the _internal index 4: About the _audit index

According to the Splunk documentation1, a bucket within a clustered index contains two key types of files: the raw data in compressed form (rawdata) and the indexes that point to the raw data (tsidx files). A bucket can be either replicated or searchable, depending on whether it has both types of files or only the rawdata file. A replicated bucket is a bucket that has been copied from one peer node to another for the purpose of data replication. A searchable bucket is a bucket that has both the rawdata and the tsidx files, and can be searched by the search heads. The types of files that exist in a bucket within a clustered index are:

• Inside a searchable bucket, there is tsidx and rawdata. This is true because a searchable bucket contains both the data and the index files, and can be searched by the search heads1.
• Inside a replicated bucket, there is both tsidx and rawdata. This is true because a replicated bucket can also be a searchable bucket, if it has both the data and the index files. However, not all replicated buckets are searchable, as some of them might only have the rawdata file, depending on the replication factor and the search factor settings1.

The other options are false because:

• Inside a replicated bucket, there is only rawdata. This is false because a replicated bucket can also have the tsidx file, if it is a searchable bucket. A replicated bucket only has the rawdata file if it is a non-searchable bucket, which means that it cannot be searched by the search heads until it gets the tsidx file from another peer node1.
• Inside a searchable bucket, there is only tsidx. This is false because a searchable bucket always has both the tsidx and the rawdata files, as they are both required for searching the data. A searchable bucket cannot exist without the rawdata file, as it contains the actual data that the tsidx file points to1.

The average run time of all searches increases as the number of CPU cores on the indexers decreases. The CPU cores are the processing units that execute the instructions and calculations for the data. The number of CPU cores on the indexers affects the search performance, because the indexers are responsible for retrieving and filtering the data from the indexes. The more CPU cores the indexers have, the faster they can process the data and return the results. The less CPU cores the indexers have, the slower they can process the data and return the results. Therefore, the average run time of all searches is inversely proportional to the number of CPU cores on the indexers. The average run time of all searches is not independent of the number of CPU cores on the indexers, because the CPU cores are an important factor for the search performance. The average run time of all searches does not decrease as the number of CPU cores on the indexers decreases, because this would imply that the search performance improves with less CPU cores, which is not true. The average run time of all searches does not increase as the number of CPU cores on the indexers increases, because this would imply that the search performance worsens with more CPU cores, which is not true

 The following artifacts are included in a Splunk diag file:

• Internal logs. These are the log files that Splunk generates to record its own activities, such as splunkd.log, metrics.log, audit.log, and others. These logs can help troubleshoot Splunk issues and monitor Splunk performance.
• Configuration files. These are the files that Splunk uses to configure various aspects of its operation, such as server.conf, indexes.conf, props.conf, transforms.conf, and others. These files can help understand Splunk settings and behavior. The following artifacts are not included in a Splunk diag file:
• OS settings. These are the settings of the operating system that Splunk runs on, such as the kernel version, the memory size, the disk space, and others. These settings are not part of the Splunk diag file, but they can be collected separately using the diag --os option.
• Customer data. These are the data that Splunk indexes and makes searchable, such as the rawdata and the tsidx files. These data are not part of the Splunk diag file, as they may contain sensitive or confidential information. For more information, see Generate a diagnostic snapshot of your Splunk Enterprise deployment in the Splunk documentation.

According to the Splunk blog1, the best method for sizing or scaling a search head cluster is to estimate the maximum concurrent number of searches and divide by the number of CPU cores per search head. This gives you an idea of how many search heads you need to handle the peak search load without overloading the CPU resources. The other options are false because:

• Estimating the maximum daily ingest volume in gigabytes and dividing by the number of CPU cores per search head is not a good method for sizing or scaling a search head cluster, as it does not account for the complexity and frequency of the searches. The ingest volume is more relevant for sizing or scaling the indexers, not the search heads2.
• Estimating the total number of searches per day and dividing by the number of CPU cores available on the search heads is not a good method for sizing or scaling a search head cluster, as it does not account for the concurrency and duration of the searches. The total number of searches per day is an average metric that does not reflect the peak search load or the search performance2.
• Dividing the number of indexers by three to achieve the correct number of search heads is not a good method for sizing or scaling a search head cluster, as it does not account for the search load or the search head capacity. The number of indexers is not directly proportional to the number of search heads, as different types of data and searches may require different amounts of resources2.

 The following is a good practice for a search head cluster deployer: The deployer must be used to distribute non-replicable configurations to search head cluster members. Non-replicable configurations are the configurations that are not replicated by the search factor, such as the apps and the server.conf settings. The deployer is the Splunk server role that distributes these configurations to the search head cluster members, ensuring that they have the same configuration. The deployer does not only distribute configurations to search head cluster members when they “phone home”, as this would cause configuration inconsistencies and delays. The deployer does not distribute configurations to search head cluster members to be valid configurations, as this implies that the configurations are invalid without the deployer. The deployer does not only distribute configurations to search head cluster members with splunk apply shcluster-bundle, as this would require manual intervention by the administrator. For more information, see Use the deployer to distribute apps and configuration updates in the Splunk documentation.

Search is not locked out when a customer has installed a 500GB Enterprise license and a 300GB, no enforcement license on the same license master. The no enforcement license allows the customer to exceed the license quota without locking search, but violations are still recorded. The customer can ingest up to 800GB of data per day without violating the license, but if they ingest more than that, they will incur a violation. However, the violation will not lock search, as the no enforcement license overrides the enforcement policy of the Enterprise license. For more information, see [No enforcement licenses] and [License violations] in the Splunk documentation.

The splunk offline --enforce-counts command will permanently decommission a peer node operating in an indexer cluster. This command will remove the peer node from the cluster and delete its data. This command should be used when the peer node is no longer needed or is being replaced by another node. The splunk stop -f command will stop the Splunk service on the peer node, but it will not decommission it from the cluster. The splunk offline -f command will take the peer node offline, but it will not delete its data or enforce the replication and search factors. The splunk decommission --enforce-counts command is not a valid Splunk command. For more information, see Remove a peer node from an indexer cluster in the Splunk documentation.

Index files (. tsidx files) are the main components of an index that store the raw data and the inverted index of terms. They take the most space in an index, especially if the raw data has many unique terms that increase the size of the inverted index. Bloom filters, source metadata, and sourcetype metadata are much smaller in comparison and do not depend on the number of unique terms in the raw data.

References:

• How the indexer stores indexes
• Splunk Enterprise Certified Architect Study Guide, page 17

 In a four site indexer cluster, the configuration that stores two searchable copies at the origin site, one searchable copy at site2, and a total of four searchable copies is site_search_factor = origin:2, site2:1, total:4. This configuration tells the cluster to maintain two copies of searchable data at the site where the data originates, one copy of searchable data at site2, and a total of four copies of searchable data across all sites. The site_search_factor determines how many copies of searchable data are maintained by the cluster for each site. The site_replication_factor determines how many copies of raw data are maintained by the cluster for each site. For more information, see Configure multisite indexer clusters with server.conf in the Splunk documentation.

The _internal index contains license-related events, such as the license usage, the license quota, the license pool, the license stack, and the license violations. These events are logged by the license manager in the license_usage.log file, which is part of the _internal index. The _audit index contains audit events, such as user actions, configuration changes, and search activity. These events are logged by the audit trail in the audit.log file, which is part of the _audit index. The _license index does not exist in Splunk, as the license-related events are stored in the _internal index. The _introspection index contains platform instrumentation data, such as the resource usage, the disk objects, the search activity, and the data ingestion. These data are logged by the introspection generator in various log files, such as resource_usage.log, disk_objects.log, search_activity.log, and data_ingestion.log, which are part of the _introspection index. For more information, see About Splunk Enterprise logging and [About the _internal index] in the Splunk documentation.

Before deploying Splunk, it is important to gather some information about the current environment, such as:

• Overall goals for the deployment: This includes the business objectives, the use cases, the expected outcomes, and the success criteria for the Splunk deployment. This information helps to define the scope, the requirements, the design, and the validation of the Splunk solution1.
• Key users: This includes the roles, the responsibilities, the expectations, and the needs of the different types of users who will interact with the Splunk deployment, such as administrators, analysts, developers, and end users. This information helps to determine the user access, the user experience, the user training, and the user feedback for the Splunk solution1.
• Data sources: This includes the types, the formats, the volumes, the locations, and the characteristics of the data that will be ingested, indexed, and searched by the Splunk deployment. This information helps to estimate the data throughput, the data retention, the data quality, and the data analysis for the Splunk solution1.

Option B, C, and D are the correct answers because they reflect the essential information that is needed before deploying Splunk. Option A is incorrect because the list of vendors for network devices is not a relevant information for the Splunk deployment. The network devices may be part of the data sources, but the vendors are not important for the Splunk solution.

References:

1: Splunk Validated Architectures

The correct tasks that the cluster manager performs in an indexer cluster are A. Generates and maintains the list of primary searchable buckets, B. If Indexer Discovery is enabled, provides the list of available peer nodes to forwarders, and D. Distributes app bundles to peer nodes. According to the Splunk documentation1, the cluster manager is responsible for these tasks, as well as managing the replication and search factors, coordinating the replication and search activities, and providing a web interface for monitoring and managing the cluster. Option C, ensuring all peer nodes are always using the same version of Splunk, is not a task of the cluster manager, but a requirement for the cluster to function properly2. Therefore, option C is incorrect, and options A, B, and D are correct.

1: About the cluster manager 2: Requirements and compatibility for indexer clusters

 The index-time props.conf attributes that impact indexing performance are LINE_BREAKER and SHOULD_LINEMERGE. These attributes determine how Splunk breaks the incoming data into events and whether it merges multiple events into one. These operations can affect the indexing speed and the disk space consumption. The REPORT attribute does not impact indexing performance, as it is used to apply transforms at search time. The ANNOTATE_PUNCT attribute does not impact indexing performance, as it is used to add punctuation metadata to events at search time. For more information, see [About props.conf and transforms.conf] in the Splunk documentation.

When converting from a single-site to a multi-site cluster, existing single-site clustered buckets will maintain replication as required according to the single-site policies, but never age out. Single-site clustered buckets are buckets that were created before the conversion to a multi-site cluster. These buckets will continue to follow the single-site replication and search factors, meaning that they will have the same number of copies and searchable copies across the cluster, regardless of the site. These buckets will never age out, meaning that they will never be frozen or deleted, unless they are manually converted to multi-site buckets. Single-site clustered buckets will not continue to replicate within the origin site, because they will be distributed across the cluster according to the single-site policies. Single-site clustered buckets will not be replicated across all peers in the multi-site cluster, because they will follow the single-site replication factor, which may be lower than the multi-site total replication factor. Single-site clustered buckets will not stop replicating within the single-site and remain on the indexer they reside on, because they will still be subject to the replication and availability rules of the cluster

The frequency in which a deployment client contacts the deployment server is controlled by the phoneHomeIntervalInSecs attribute in deploymentclient.conf. This attribute specifies how often the deployment client checks in with the deployment server to get updates on the apps and configurations that it should receive. The polling_interval attribute in outputs.conf controls how often the forwarder sends data to the indexer or another forwarder. The polling_interval attribute in deploymentclient.conf and the phoneHomeIntervalInSecs attribute in outputs.conf are not valid Splunk attributes. For more information, see Configure deployment clients and Configure forwarders with outputs.conf in the Splunk documentation.
