Juniper JN0-451 Mist AI - Specialist (JNCIS-MistAI) Exam Practice Test

In this scenario, you would begin troubleshooting by checking the WLAN-level Pre-Shared Keys.

According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide1, you can configure a time-based setting for WLAN-level Pre-Shared Keys (PSKs) that will reset the key after a specified interval. This feature is useful for enhancing security and preventing unauthorized access. If a user reports that the Wi-Fi worked for a week and now it does not work, you should check the WLAN-level PSK settings and see if the key has been changed.

References:

When deploying three WLAN 2.4 GHz networks in your US-based site while ensuring that each network frequency is unique and does not overlap with other frequency channels, you should use OFDM channels 1, 6 and 11. So the correct answers are B.1, D.6, and A.11.

According to the exhibit, the WLAN has a minimum basic rate of 24 Mbps for both 2.4 GHz and 5 GHz bands. This corresponds to the high-density data rate setting in Mist, which disables all data rates below 24 Mbps. This setting is recommended for high density designs, where clients have enough signal strength and quality to operate at higher rates.

References:

Basic data rates are the required data rates that all devices on a wireless network must support in order to connect to the network. These rates are used for management and control frames and can affect the performance of the network.

According to the Lecture 3 - Radio Frequency and Antenna Fundamentals - Part 2 document2, basic data rates are required data rates that all devices must support to communicate on a WLAN.

References:

According to the Wi-Fi - Radio Modulation - TutorialsPoint document1, 64 QAM is a modulation method that will result in the highest theoretical data rates among the given options. 64 QAM uses both phase and amplitude modulation to encode six bits of information into each transmitted symbol. It can achieve up to 54 Mbps in the 802.11a and g systems.

References:

According to the Initial AP Connection and VLANs & Static IP addresses - Mist document1, when a Juniper Mist AP boots up for the first time, it will expect to see a trunked port or the native VLAN=1 and will send a DHCP request on that VLAN. The AP will attempt to connect to the Mist cloud using port 443, which is the default HTTPS port.

References:

If a customer added an Apple TV in their conference room so that employees can easily share their screen but the Apple TV cannot be discovered by the employees’ devices, two settings that could be causing this problem are MDNS and Broadcast/Multicast. So the correct answers are A. MDNS and B. Broadcast/Multicast.

The Compatible WLAN data rate setting is required for legacy 2.4 GHz scanners to connect to the WLAN.

According to the Data Rates - Mist document4, the WLAN data rate setting that is required for legacy 2.4 GHz scanners to connect to the WLAN is Compatible. This setting enables all data rates from 1 Mbps to 54 Mbps for both 2.4 GHz and 5 GHz bands. This setting is recommended for legacy devices that need low data rates to connect.

References:

According to the Mist documentation1, a Mist AP will pull a management IP address from the Native VLAN by default. However, if the Local Status Page is configured for the Site, all the site APs will pull their own IP address from the Management VLAN, but also addresses for each of the VLANs configured on the AP. This is because each AP creates a Switch Virtual Interface (SVI) for each VLAN on its eth0 interface.

The Local Status Page is a feature that allows you to access information about an AP’s status and configuration through a web browser by connecting to its IP address2. This feature can be enabled or disabled at the site level under Site Settings > Access Points > Advanced Settings.

According to the exhibit, the organization has a total of two licenses for Marvis wireless, and one of them is in use. Therefore, the organization has one available license and one used license for Marvis wireless.
